NAVYPEDIA


Oskemen 2013

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
301 Астана [Astana] 302 Орал [Oral] 303 Алматы [Almaty] 304 Ақтау [Aktau] 305 Атырау [Atyrau] 306 Тараз [Taraz] 307 Ɵскемен [Oskemen]	Zenit, Oral: 301-307	1998: 301 2000: 302 2002: 305 2003: 303 2004: 304 2005: 306 2006: 307	None	None	in service (2020): 301-307

Technical data

Displacement standard, t	40
Displacement full, t	50
Length, m	23.9
Breadth, m	5.00
Draught, m	1.50
No of shafts	2
Machinery	2 M-50 diesels
Power, h. p.	2400
Max speed, kts	30
Fuel, t	diesel oil
Endurance, nm(kts)	1100(15)
Armament	301-303: 1 x 1 - 30/82 2A42 304-306: 1 x 1 - 12.7/79 307: 1 x 1 - 14.5/93
Electronic equipment	Lotsiya radar
Complement	12

Graphics

Project history

Coast Guard. Modified Soviet project 1400M. First five boats belong to project 0200 'Burkit', last two to project 0200M 'Burkit-M'.

Modernizations

late 2010s, Aktau, Taraz: - 1 x 1 - 12.7/79; + 1 x 2 - 23/82 ZU-23-2

Naval service

No significant events.
