  3-go

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
第3号駆潜艇 [3-go]			Tsurumi, Yokohama	4/1935	6.6.1936	10.1936	captured 8.1945, scuttled 11.7.1946

Technical data

Displacement standard, t	270
Displacement full, t	284
Length, m	53.0 pp 55.0 wl 56.1 oa
Breadth, m	5.60
Draught, m	2.18
No of shafts	2
Machinery	2 diesels
Power, h. p.	2500
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)	1500(14)
Armament	1 x 2 - 40/62 HI 91-shiki, 2 x 1 - 7.7/80, 2 DCR (12)
Electronic equipment	SCAM sonar
Complement	45

Standard scale images

Graphics

Project history

2nd Supplementary programme of 1934 provided building of one chaser on slightly modified design of Ch1, thoroughly redesigned towards reduction of the upper weight. ChЗ very much resembled a prototype, but was a little bit less and had only one rudder instead of two.

Modernizations

1944: - 2 x 1 - 7.7/80; + 1 x 3 - 25/60 96-shiki, 2 DCT (36 DC at all), 93-shiki hydrophone
