101-GO patrol ship (1922 / 1942)





101-go Many thanks to Wolfgang Stöhr for additional information on this page.

Ships


Name No Yard No Builder Laid down Launched Comp Fate
第101号哨戒艇 [101-go] (ex-Thracian), 3.1944- 第1号練習艇 [1-go]   512 Hawthorn Leslie, Hebburn, UK 1.1919 5.3.1920 4.1922 // 11.1942 test ship 3.1944, surrendered 8.1945, to United Kingdom 9.1945, BU


Technical data


Displacement standard, t

905

Displacement full, t

1213

Length, m80.8 pp 84.1 oa
Breadth, m8.18
Draught, m3.00
No of shafts

2

Machinery

2 sets Brown-Curtis geared steam turbines, 3 Yarrow boilers (2 operational)

Power, h. p.

10000

Max speed, kts

25

Fuel, t

oil 301

Endurance, nm(kts)2750(15)
Armament

3 x 1 - 102/40 QF Mk IV, 2 x 1 - 25/60 96-shiki, 1 x 2 - 533 TT, 2 DCT

Electronic equipmentpresumably type 124 or type 127 sonar
Complement90


Standard scale images


<i>101-go</i> 1942
101-go 1942
<i>101-go</i> 1945
101-go 1945


Graphics


<i> 101-go</i> <i>Many thanks to Wolfgang Stöhr for additional information on this page.</i>
101-go Many thanks to Wolfgang Stöhr for additional information on this page.


Project history

After capture by Japan in the beginning of 1942 of extensive possession in South-East Asia, Japanese has got some number of enemy ships in damaged condition, abandoned by Americans, British and Dutch at retreat. Part of these ships has been repaired by Japanese and commissioned by IJN as patrols. Three destroyers, British Thracian, American Stewart and Dutch Banckert, become in the IJN patrols Р101, Р102 and Р106, have appeared the largest trophies. Remaining were former minesweepers, tugs and colonial service vessels of Dutch and American Navies.

Р101 (ex-British destroyer Thracian) was captured by Japanese at Hong Kong 25.12.1941 in partly scuttled condition on shallow water. She was salvaged 10.7.1942 and after repair and re-arming commissioned 25.11.1942 as patrol Р101. 15.3.1944 she was reclassified as training ship and used for new radars trials.

Modernizations 1.

1944: - 1 x 2 - 533 TT; + 1 x 4 - 610 TT, 3-shiki 2-go radar
