SAKURA destroyers (1912)





Sakura

Ships


Name No Yard No Builder Laid down Launched Comp Fate
櫻 [Sakura]     Maizuru K K 3/1911 20/12/1911 5/1912 stricken 1931
橘 [Tachibana]     Maizuru K K 4/1911 27/1/1912 6/1912 stricken 1931


Technical data


Displacement normal, t605
Displacement full, t

830

Length, m

79.2 pp 83.6 oa

Breadth, m

7.30

Draught, m

2.20

No of shafts

3

Machinery

3 4-cyl VTE, 5 Kampon boilers

Power, h. p.

9500

Max speed, kts

30

Fuel, t

coal 228 + oil 30

Endurance, nm(kts)2400(15)
Armament

1 x 1 - 120/40 41-shiki, 4 x 1 - 76/40 41-shiki, 2 x 2 - 450 TT

Complement

92



Standard scale images


<i>Sakura</i> 1913
Sakura 1913


Graphics


<i> Sakura</i>
Sakura


Ship project history


First destroyers, designed in Japan. First Japanese 2nd class destroyers created as alternative to powerful but very expensive Umikaze class ships. The idea has justified itself: despite modest battle characteristics Sakura became a prototype of the largest series of destroyers built in Japan in days of First World War (Kaba and Algerien classes).

Modernizations


None.

Naval service


No significant events.
