Zao 2009

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
つがる [Tsugaru]	PL02, 12.1985- PLH02		Ishikawajima, Harima	18.4.1978	6.12.1978	17.4.1979	in service (2019)
おおすみ [Osumi]	PL03, 12.1985- PLH03		Mitsui, Tamano	1.9.1978	1.6.1979	18.10.1979	in service (2019)
うらが [Uraga], 3.1997- はやと [Hayato], 6.2014- うるま [Uruma]	PL04, 12.1985- PLH04		Hitachi, Maizuru	14.3.1979	12.10.1979	5.3.1980	in service (2019)
ざおう [Zao]	PL05, 12.1985- PLH05		Mitsubishi, Nagasaki	23.10.1980	29.10.1981	19.3.1983	in service (2019)
ちくぜん [Chikuzen], 10.2013- おきなわ [Okinawa]	PL06, 12.1985- PLH06		Kawasaki, Kobe	20.4.1982	18.3.1983	28.9.1983	in service (2019)
せっつ [Settsu]	PL07, 12.1985- PLH07		Sumitomo, Uraga	5.4.1983	21.4.1984	27.9.1984	in service (2019)

Technical data

Displacement standard, t	3730
Displacement normal, t	4037
Length, m	100.0 wl 105.4 oa
Breadth, m	14.6
Draught, m	4.90
No of shafts	2
Machinery	2 Nippon Kokan-Pielstick 12PC2-5 V400 diesels
Power, h. p.	15600
Max speed, kts	22
Fuel, t	diesel oil 864
Endurance, nm(kts)	5700(18)
Armament	02: 1 x 1 - 40/60 Mk 3, 1 x 1 - 20/70 Mk 10, 1 helicopter (Bell 212) 03: 1 x 1 - 40/60 Mk 3, 1 helicopter (Bell 212) 04: 1 x 1 - 35/90 type 87, 1 helicopter (Bell 212) 05-07: 1 x 1 - 35/90 type 87, 1 x 1 - 20/70 Mk 10, 1 helicopter (Bell 212)
Electronic equipment	JMA 1596, JMA1576, helicopter control radars
Complement	71

Standard scale images

Graphics

Project history

Intended to operate 100nm or more to sea. Have two pairs of fin stabilizers and FLUME-type passive stabilization tanks in the superstructure. The engines were manufactured by different builders.

Modernizations

None.

Naval service

No significant events.
