Kuwano 2005

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
てしお [Teshio], 11.1995- なつい [Natsui]	PM01		Shikoku DY, Kochi		30.5.1980	30.9.1980	deleted 6.2013
おいらせ [Oirase], 2.2004- きたかみ [Kitakami]	PM02		Naikai, Taguma		15.5.1980	29.8.1980	stricken 2.2018
えちぜん [Echizen], 3.2008- びほろ [Bihoro]	PM03		Usuki Iron Wks, Usuki		2.6.1980	30.9.1980	deleted 3.2013
とかち [Tokachi]	PM04		Narazaki, Muroran		21.11.1980	24.3.1981	stricken 9.2017
ひたち [Hitachi]	PM05		Tohoku SY, Shiogama		15.11.1980	19.3.1981	stricken 2.2018
おきつ [Okitsu]	PM06		Usuki Iron Wks, Usuki		5.12.1980	17.3.1981	deleted 6.2011
いさづ [Isazu]	PM07		Naikai, Taguma		29.10.1981	18.2.1982	stricken 10.2017
ちとせ [Chitose]	PM08		Shikoku DY, Kochi		7.7.1981	17.11.1982	in service (2019)
くわの [Kuwano], 2009- まべち [Mabechi]	PM09		Naikai, Taguma		8/1981	10.3.1983	stricken 12.2018
そらち [Sorachi], 2018- いさづ [Isazu]	PM10		Tohoku SY, Shiogama		27.4.1984	27.9.1984	in service (2019)
ゆうばり [Yubari]	PM11		Usuki Iron Wks, Usuki		20.8.1985	28.11.1985	in service (2019)
もとうら [Motoura]	PM12		Shikoku DY, Takamatsu		7.8.1986	21.11.1986	in service (2019)
かの [Kano], 2010- いしかり [Ishikari], 2011- むろみ [Muromi], 2015- くろせ [Kurose]	PM13		Naikai, Taguma		7.8.1986	13.11.1986	in service (2019)
せんだい [Sendai], 2015- つるみ [Tsurumi], 2016- たかとり [Takatori]	PM14		Shikoku DY, Takamatsu		21.1.1988	1.6.1988	in service (2019)

Technical data

Displacement standard, t	630
Displacement normal, t	01-11, 13, 14: 670 12: 692
Length, m	63.0 pp 67.8 oa
Breadth, m	7.90
Draught, m	2.65
No of shafts	2
Machinery	01-11, 13, 14: 2 Fuji 6S32F diesels 12: 2 Niigata 6M31EX(14) diesels
Power, h. p.	3000
Max speed, kts	18
Fuel, t	diesel oil
Endurance, nm(kts)	01-11, 13, 14: 3200(16) 12: 3900(16)
Armament	1 x 3 - 20/76 JM-61-MB Sea Vulcan
Electronic equipment	2x JMA 159B radars
Complement	33

Standard scale images

Graphics

Project history

Medium patrols.

Modernizations

None.

Naval service

No significant events.
