NAVYPEDIA


Koshiki 2008

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
しれとこ [Shiretoko]	PL101		Mitsui, Tamano		13.7.1978	8.11.1978	deleted 3.2012
えさん [Esan]	PL102		Sumitomo, Oshima		8/1978	16.11.1978	deleted 12.2008
わかさ [Wakasa], 1.2015- くさかき [Kusakaki]	PL103		Kawasaki, Kobe		8/1978	29.11.1978	deleted 10.2015
やひこ [Yahiko], 9.1999- しまんと [Shimanto], 10.2004- きい [Kii], 6.2014- あつみ [Atsumi]	PL104		Mitsubishi, Shimonoseki		8/1978	16.11.1978	deleted 10.2015
もとぶ [Motobu], 10.2000- おじか [Ojika]	PL105		Sasebo DY		8/1978	29.11.1978	collision 20.10.2000, stricken
りしり [Rishiri]	PL106		Shikoku DY		27.3.1979	12.9.1979	deleted 3.2006
まつしま [Matsushima]	PL107		Thohoku DY		11.4.1979	14.9.1979	deleted 2.2009
いわき [Iwaki]	PL108		Naikai, Innoshima		28.3.1979	10.8.1979	deleted 3.2006
しきね [Shikine]	PL109		Usuki SY, Usuki		27.4.1979	20.9.1979	deleted 9.2009
するが [Suruga]	PL110		Kurushima DY, Onishi		20.4.1979	28.9.1979	deleted 2.2010
れぶん [Rebun]	PL111		Narasaki SY, Muroran		6/1979	21.11.1979	deleted 12.2008
ちょうかい [Chokai]	PL112		Nipponkai HI, Toyama		6/1979	30.11.1979	deleted 3.2008
あしずり [Ashizuri], 11.1997- のじま [Nojima]	PL113		Sanoyasu DY, Oshima		6/1979	31.10.1979	deleted 3.2006
おき [Oki], 11.1997- とさ [Tosa]	PL114		Tsuneishi SY, Numakuma		6/1979	16.11.1979	deleted 1.2009
のと [Noto], 1.2015- ようてい [Yotei]	PL115		Miho SY, Shimizu		7/1979	30.11.1979	deleted 12.2015
よなくに [Yonakuni]	PL116		Hiyashigane SY, Nagasaki		6/1979	31.10.1979	deleted 2.2005
だいせつ [Daisetsu], 4.1988- くだか [Kudaka], 8.1994- くりこま [Kurikoma], 4.2000- いわみ [Iwami], 12.2008- れぶん [Rebun], 12.2013- するが [Suruga]	PL117		Hakodate DY		22.8.1979	31.1.1980	deleted 1.2016
しもきた [Shimokita]	PL118		Ishikawajima, Tokyo		9/1979	12.3.1980	deleted 3.2012
すずか [Suzuka]	PL119		Kanasashi SY, Toyohashi		4.10.1979	7.3.1980	deleted 2.2010
くにさき [Kunisaki]	PL120		Koyo DY, Mihara		8.10.1979	29.2.1980	deleted 10.2016
げんかい [Genkai], 2.2005- あまぎ [Amagi]	PL121		Oshima SY, Oshima		9/1979	31.1.1980	deleted 2.2008
ごとう [Goto], 12.2008- いわみ [Iwami], 8.2013- いとしま [Itoshima]	PL122		Onomichi SY, Onomichi		10/1979	29.2.1980	deleted 10.2015
こしき [Koshiki]	PL123		Kasado DY, Kasado		9/1979	25.1.1980	deleted 2.2010
はてるま [Hateruma]	PL124		Osaka DY		11/1979	12.3.1980	deleted 2.2008
かとり [Katori]	PL125		Tohoku DY, Shiogama		5/1980	17.10.1980	deleted 10.2016
くにがみ [Kunigami], 2.2009- まつしま [Matsushima], 8.2014- おしか [Oshika]	PL126		Kanda SY, Kawashiri		28.3.1980	21.10.1980	deleted 1.2016
えとも [Etomo]	PL127		Naikai, Innoshima		30.9.1981	17.3.1982	deleted 9.2016
ましゅう [Mashu], 3.1997- あまぎ [Amagi], 2004- よなくに [Yonaguni], 12.2008- えさん [Esan]	PL128		Shikoku DY, Takamatsu		14.10.1981	12.3.1982	deleted 9.2016

Technical data

Displacement standard, t	966 - 974
Displacement normal, t	1350 - 1360
Length, m	73.6 pp 77.8 oa
Breadth, m	9.60
Draught, m	3.42
No of shafts	2
Machinery	101, 103, 107, 108, 110-113, 117, 121, 122, 124, 127: 2 Fuji S40B diesels 102, 104-106, 109, 114-116, 118-120, 123, 125, 126, 128: 2 Niigata 8MA40 diesels
Power, h. p.	7000
Max speed, kts	20
Fuel, t	diesel oil 191
Endurance, nm(kts)	4400(17)
Armament	101-104: 1 x 1 - 40/60 Mk 3, 1 x 1 - 20/70 Mk 10 105-117, 119-121, 123: 1 x 1 - 40/60 Mk 3 118, 122, 124-128: 1 x 1 - 35/90 type 87
Electronic equipment	JMA 1596, JMA 1576 radars
Complement	41

Standard scale images

Graphics

Project history

Mass-produced development of the Erimo class for 200nm EEZ patrol duties.

Modernizations

None.

Naval service

No significant events.
