MURAKUMO patrol craft (1978-1983)
Kawagiri 2004
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| むらくも [Murakumo] | PC201 | Mitsubishi, Shimonoseki | 24.3.1978 | deleted 8.2002 | |||
| きたぐも [Kitagumo] | PC202 | Hitachi, Kanagawa | 17.3.1978 | deleted 2.2011 | |||
| ゆきぐも [Yukigumo] | PC203 | Hitachi, Kanagawa | 27.9.1978 | deleted 2.2011 | |||
| あさぐも [Asagumo] | PC204 | Mitsubishi, Shimonoseki | 21.9.1978 | deleted 2.2005 | |||
| はやぐも [Hayagumo] | PC205 | Mitsubishi, Shimonoseki | 30.1.1979 | deleted 3.2006 | |||
| あきぐも [Akigumo] | PC206 | Hitachi, Kanagawa | 28.2.1979 | deleted 2.2008 | |||
| やえぐも [Yaegumo] | PC207 | Mitsubishi, Shimonoseki | 16.3.1979 | deleted 2.2008 | |||
| なつぐも [Natsugumo] | PC208 | Hitachi, Kanagawa | 22.3.1979 | deleted 2.2008 | |||
| やまぎり [Yamagiri] | PC209 | Hitachi, Kanagawa | 29.6.1979 | deleted 3.2003 | |||
| かわぎり [Kawagiri] | PC210 | Hitachi, Kanagawa | 27.7.1979 | deleted 2.2012 | |||
| てるづき [Teruzuki], 1999- びざん [Bizan], 2008- とさぎり [Tosagiri] | PC211 | Maizuru HI | 26.6.1979 | deleted 2.2012 | |||
| なつづき [Natsuzuki] | PC212 | Maizuru HI | 26.7.1979 | deleted 2.2009 | |||
| みやづき [Miyazuki] | PC213 | Hitachi, Kanagawa | 13.3.1980 | deleted 3.2006 | |||
| にじぐも [Nijigumo] | PC214 | Mitsubishi, Shimonoseki | 29.1.1981 | deleted 3.2009 | |||
| たつぐも [Tatsugumo] | PC215 | Mitsubishi, Shimonoseki | 19.3.1981 | deleted 2.2009 | |||
| はまゆき [Hamayuki], 2000- いせゆき [Iseyuki] | PC216 | Hitachi, Kanagawa | 27.2.1981 | deleted 10.2018 | |||
| いそなみ [Isonami] | PC217 | Mitsubishi, Shimonoseki | 19.3.1981 | deleted 1.2014 | |||
| なごづき [Nagozuki] | PC218 | Hitachi, Kanagawa | 29.1.1981 | deleted 1.2014 | |||
| やえづき [Yaezuki] | PC219 | Hitachi, Kanagawa | 19.3.1981 | deleted 2.2014 | |||
| やまゆき [Yamayuki], 2006- はまゆき [Hamayuki] | PC220 | Hitachi, Kanagawa | 16.2.1982 | deleted 1.2019 | |||
| こまゆき [Komayuki] | PC221 | Mitsubishi, Shimonoseki | 10.2.1982 | deleted 2.2011 | |||
| うみぎり [Umigiri] | PC222 | Hitachi, Kanagawa | 17.2.1983 | in service (2019) | |||
| あさぎり [Asagiri] | PC223 | Mitsubishi, Shimonoseki | 23.2.1983 | in service (2019) |
Technical data
| Displacement standard, t | 88 |
|---|---|
| Displacement normal, t | 125 |
| Length, m | 28.5 pp 31.0 oa |
| Breadth, m | 6.30 |
| Draught, m | 1.70 |
| No of shafts | 2 |
| Machinery | 2 Ikegai-MTU 16V652 TB81 diesels |
| Power, h. p. | 4800 |
| Max speed, kts | 31 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 350(28) |
| Armament | 1 x 1 - 12.7/90 |
| Electronic equipment | radar |
| Complement | 11 |
Graphics
Kawagiri 2004
Project history
Hull sides are painted gray, superstructure white. Have a firefighting monitor on the foredeck, to port.
Modernizations
None.
Naval service
No significant events.
