"T1" type torpedo boats (1-GO) (1941)





2-go

Ships


Names Builders Commissioned Losses Transfers Discarding

第1号魚雷艇 -  第6号魚雷艇 [1-go - 6-go]

Yokohama Yacht Co., Tsurumi: 1-go - 6-go

10-12/1941: 1-go - 6-go

2-go (19.9.1943), 3-go (19.9.1943), 4-go (24.3.1944), 5-go (30.1.1944), 6-go (30.1.1944)

none

after 8.1945: 1-go


Technical data


Displacement normal, t17
Displacement full, t20.5
Length, m

18.3

Breadth, m

4.30

Draught, m

0.65

No of shafts3
Machinery

2 94-shiki petrol engines + 1 M-gata cruising petrol engine

Power, h. p.

1800 + 60

Max speed, kts

38.5

Fuel, tpetrol
Endurance, nm(kts)210(30)
Armament

2 x 1 - 7.7/80, 2 - 450 TT or 2 DCR (6)

Complement7


Standard scale images


<i>1-go</i> 1941
1-go 1941


Graphics


<i> 2-go</i>
2-go


Project history

First serial Japanese MTBs, built under 4th Supplementary programme of 1939. Created on the basis of experimental boat of B type. Wooden hull with V-shaped frames.

Modernizations

None.

Naval service

1-go was badly damaged in a storm 14.12.1942 and after repair used for training only.
