Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
舞子 [Maiko] (ex-Macau)		1276	Yarrow, Scotstoun, UK		1909	1909 // 8.1943	surrendered 8.1945, to China 1946 (五峰 [Wu Feng])

Technical data

Displacement normal, t	133
Displacement full, t
Length, m	36.5
Breadth, m	6.02
Draught, m	0.66
No of shafts	2
Machinery	2 VTE,  1 Yarrow boiler
Power, h. p.	250
Max speed, kts	11.8
Fuel, t	coal
Endurance, nm(kts)
Armament	2 x 1 - 57/40 6pdr Hotchkiss Mk I, 3 x 1 - 7.7/80
Complement	24

Standard scale images

Graphics

Project history

Portuguese river gunboat Macau was captured by Japanese in 1943, commissioned by IJN 15.8.1943 as Maiko.

Modernizations

None.

Naval service

Maiko surrendered at Canton in August, 1945 and transferred to China.
