NAVYPEDIA


Giuliano Prini 2005

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Salvatore Pelosi	S522		Italcantieri, Monfalcone	23.7.1985	29.11.1986	14.7.1988	in service (2019)
Giuliano Prini	S523		Italcantieri, Monfalcone	30.7.1987	12.12.1987	11.11.1989	in service (2019)

Technical data

Displacement standard, t
Displacement normal, t	1476 / 1680
Length, m	64.4
Breadth, m	6.83
Draught, m	5.66
No of shafts	1
Machinery	3 GMT A210-16NM diesel-generators, 1 Marelli electric motor
Power, h. p.	3515
Max speed, kts	12 / 20
Fuel, t	diesel oil 144
Endurance, nm(kts)	10000(11) / 250(4)
Armament	6 - 533 TT (6 bow B-512, 12 torpedoes, inc. Sub-Harpoon SSM (4 UGM-84))
Electronic equipment	BPS-704 radar, IPD-70/S, MD 100S, Velox M5 sonars, BLD-727 Thetis ECM suite, BSN-716(v)2 SACTIS CCS
Complement	50
Diving depth operational, m	300

Standard scale images

Graphics

Project history

This is a slightly lengthened, improved version of the original Sauro class, bought because the new S90 was not yet ready. The two units were ordered 7.3.1983. They are capable of diving deeper and are capable of firing Sub-Harpoon missiles. A single pressure-proof bulkhead was added to provide a pressure-proof internal space to shells the crew in the event the submarine sank.

Modernizations

2002, Salvatore Pelosi; 2003, Giuliano Prini: - BSN-716(v)2 CCS; + ISUS 90 CCS

Naval service

No significant events.
