Alagi 1937

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Adua			CRDA, Monfalcone	2.1936	13.9.1936	11.1936	sunk 30.9.1941
Alagi			CRDA, Monfalcone	2.1936	15.11.1936	2.1937	discarded 5.1947
Aradam			CRDA, Monfalcone	2.1936	18.10.1936	1.1937	scuttled 9.9.1943
Ascianghi			OTO, Muggiano	6.1936	14.2.1937	10.1937 // ---	to Brazil 3.1937 (Tamoio)
Ascianghi			OTO, Muggiano	1.1937	5.12.1937	3.1938	sunk 23.7.1943
Axum			CRDA, Monfalcone	2.1936	27.9.1936	12.1938	scuttled 28.12.1943
Beilul			OTO, Muggiano	7.1937	22.5.1938	9.1938	captured by Germany 9.9.1943
Dagabur			Tosi, Taranto	4.1936	22.11.1936	4.1937	sunk 12.8.1942
Dessié			Tosi, Taranto	4.1936	22.11.1936	4.1937	sunk 28.11.1942
Durbo			OTO, Muggiano	3.1937	6.3.1938	7.1938	sunk 18.10.1940
Gondar			OTO, Muggiano	11.1936	30.12.1936	10.1937 // ---	to Brazil 3.1937 (Timbira)
Gondar			OTO, Muggiano	1.1937	3.10.1937	2.1938	scuttled 30.11.1940
Lafolé			OTO, Muggiano	6.1937	10.4.1938	8.1938	sunk 20.10.1940
Macallé			OTO, Muggiano	3.1936	29.10.1936	3.1937	wrecked 15.6.1940
Neghelli			OTO, Muggiano	1936	28.11.1936	10.1937 // ---	to Brazil 3.1937 (Tupi)
Neghelli			OTO, Muggiano	1.1937	7.11.1937	2.1938	sunk 19.1.1941
Sciré			OTO, Muggiano	1.1937	6.1.1938	3.1938	sunk 10.8.1942
Tembien			OTO, Muggiano	2.1937	6.2.1938	7.1938	sunk 2.8.1941
Uarsciek			Tosi, Taranto	12.1936	19.9.1937	12.1937	sunk 15.12.1942
Uebi Scebeli			Tosi, Taranto	1.1937	3.10.1937	12.1937	scuttled 29.6.1940

Technical data

Displacement standard, t	623
Displacement normal, t	680 / 844
Length, m	60.2
Breadth, m	6.45
Draught, m	4.70
No of shafts	2
Machinery	Adua, Alagi, Aradam, Axum: 2 CRDA diesels / 2 CRDA electric motors Ascianghi, Beilul, Durbo, Gondar, Lafolé, Macallé, Neghelli, Sciré, Tembien: 2 Fiat diesels / 2 Marelli electric motors Dagabur, Dessié, Uarsciek, Uebi Scebeli: 2 Tosi diesels / 2 Marelli electric motors
Power, h. p.	1200 / 800
Max speed, kts	14 / 7.5
Fuel, t	diesel oil 80
Endurance, nm(kts)	2200(14) / 74(4)
Armament	1 x 1 - 100/47 OTO 1935, 2 x 1 - 13.2/76 or 2 x 2 - 13.2/76, 6 - 533 TT (4 bow, 2 stern, 12)
Electronic equipment	hydrophone
Complement	45
Diving depth operational, m	80

Standard scale images

Graphics

Project history

Repetition of Perla class without any significant differences. Three more submarines of this class already after they were laid down were sold to Brazil in September, 1937.

On Adua, Alagi, Gondar, Sciré and Tembien in days of war CT size was moderated. Gondar and Sciré in 1940-1941 were converted for transportation of human torpedoes. 100mm/47 gun has been thus removed, and on a deck three cylindrical transportation containers were installed.

Modernizations

1940 - 1941, Gondar, Sciré: - 1 x 1 - 100/47; + 3 SLC human torpedoes.

Naval service

Macallé was wrecked on reefs 15.6.1940 near Port Sudan after all the crew had been poisoned by halons from air-conditioning system. Uebi Scebeli was scuttled 29.6.1940 W of Crete after attack of British destroyers Dainty and Ilex. Gondar was scuttled by crew 30.9.1940 near Alexandria after attack of British destroyers Diamond and Stuart. Durbo was sunk 18.10.1940 E of Gibraltar by British destroyers Firedrake and Wrestler. Lafolé was sunk 20.10.1940 N of Melilla by British destroyers Gallant, Griffin and Hotspur. Neghelli was sunk 19.1.1941 at coast of Greece by British destroyer Greyhound. Tembien was sunk 2.8.1941 by ramming of British cruiser Hermione at coast of Tunisia. Adua was sunk 30.9.1941 E of Cartagena by British destroyers Gurkha and Legion. Sciré was sunk 10.8.1942 near Haifa by British armed trawler Islay. Dagabur was sunk 12.8.1942 by ramming of British destroyer Wolverine. Dessié was sunk 28.11.1942 near Bon by British destroyers Quiberon and Quentin. Uarsciek was sunk 15.12.1942 S of Malta by British destroyer Petard and Greek destroyer Vasilissa Olga. Ascianghi was sunk 23.7.1943 S of Sicily by British destroyers Eclipse and Laforey. Aradam was scuttled by crew 9.9.1943 at Genoa, raised by Germans, never commissioned by Kriegsmarine, and sunk by Allied aircraft 4.9.1944. Axum ran aground at Western coast of Greece and was scuttled by crew 28.12.1943. Beilul was captured 9.9.1943 by German troops in Monfalcone harbour, but never commissioned by Kriegsmarine and in May, 1945 sunk by Allied aircraft.
