STEFANO TÜRR experimental motor torpedo boat (1937)





Stefano Türr during trials

Ships


Names Builders Completed Losses Transfers Discarding

Stefano Türr

CMA, Marina di Pisa: Stefano Türr

1937: Stefano Türr

none

none

7/1941: Stefano Türr



Technical data


Displacement standard, t

59

Displacement full, t64
Length, m30.7 pp 32.0 oa
Breadth, m5.95
Draught, m0.86
No of shafts

4

Machinery

4 Fiat diesels

Power, h. p.

3000

Max speed, kts

30

Fuel, t

diesel oil

Endurance, nm(kts)750(25)
Armament

3 x 1 - 13.2/76, 1 x 1 - 6.5/115, 4 - 450 TT, 12 DC

Electronic equipmentpresumably hydrophone
Complement

16



Standard scale images


<i>Stefano Türr</i> 1937
Stefano Türr 1937


Graphics


<i> Stefano Türr </i>during trials
Stefano Türr during trials


Project history

Experimental MTB with increased, in comparison with all previous Italian boats, displacement. Design was developed by Baglietto. In a hull structure aluminium alloys were widely used for the weight decrease. Boat was appeared unsuccessful, never reached designed 34kts.

Modernizations

None.

Naval service

No significant events.
