821 2006

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
820-823	Israeli Aircraft Industries, Be'er Sheva: 820-823	1992-1993: 820-823	none	none	in service (2019): 820-823

Technical data

Displacement standard, t	58
Displacement full, t	65
Length, m	25.0
Breadth, m	5.65
Draught, m	0.9 hull 1.80 propellers
No of shafts	2
Machinery	2 MTU 12V396 TE94 diesels
Power, h. p.	4180
Max speed, kts	46
Fuel, t	diesel oil
Endurance, nm(kts)	1200(17)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90
Electronic equipment	Raytheon radar
Complement	9

Standard scale images

Graphics

Project history

Super Dvora Mk 2, lengthened Mk 1. Aluminium construction. Can be armed with depth charges, ASW torpedoes or 130mm barrage rocket launchers.

Modernizations

2000s, most: - 1 x 1 - 20/70; + 1 x 1 - 25/75 Typhoon, MSIS e/o system

Naval service

No significant events.
