817 2010

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
810-818	Israeli Aircraft Industries, Be'er Sheva: 810-818	1989: 810, 811 1990: 812-815 1992: 816-818	none	none	in service (2019): 810-818

Technical data

Displacement standard, t	48
Displacement full, t	54
Length, m	21.6
Breadth, m	5.50
Draught, m	0.9 hull 1.80 propellers
No of shafts	2
Machinery	2 General Motors Detroit Diesel 16V92TA diesels
Power, h. p.	1380
Max speed, kts	36
Fuel, t	diesel oil
Endurance, nm(kts)	1200(17)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90
Electronic equipment	Raytheon radar
Complement	9

Standard scale images

Graphics

Project history

Improved Dvora design without Gabriels. Aluminium construction. Can be armed with depth charges, ASW torpedoes or 130mm barrage rocket launchers.

Modernizations

2000s, most: - 1 x 1 - 20/70; + 1 x 1 - 25/75 Typhoon, MSIS e/o system

2000s, 815: - 1 x 1 - 20/70; + 1 x 3 - 12.7/90, MSIS e/o system

Naval service

No significant events.
