Sepinggan 2010

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
Mansalar Pohawang Ratu Samban Tanjung Pandangan Kembang Sambas Enggano Simeulue I-1-10 Sepinggan Balongan Jemur Panda Sinyaru Serayu Belinyu Samalona Bokor Pulau Bengkoang Tahuna Baruk Maribaya II-10-01 Telaga Tujuh Tabuan	PT Palindo Marine or PT Infinity Global Mandiri: 23 boats	1993-2010: 23 boats	none	none	in service (2019): 23 boats

Technical data

Displacement standard, t
Displacement full, t	~80
Length, m	28.0
Breadth, m	4.50
Draught, m	2.20
No of shafts	2
Machinery	2 Caterpillar CAT3408 diesels
Power, h. p.	1600
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	1 x 1 - 12.7/90
Electronic equipment	JMA-2300 radar
Complement

Graphics

Project history

Patrol boats of domestic design.

Modernizations

None.

Naval service

No significant events.
