CHUNDAMANI patrol ships (2013)
Chundamani
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| Chundamani | P116 | Daya Radar Utama, Jakarta | 2013 | in service (2019) | |||
| Kalawai | P117 | Daya Radar Utama, Jakarta | 8.2013 | in service (2019) | |||
| Gandiwa | P118 | Daya Radar Utama, Jakarta | 8.2013 | in service (2019) |
Technical data
| Displacement standard, t | 574 |
|---|---|
| Displacement full, t |
|
| Length, m | 61.8 |
| Breadth, m | 9.70 |
| Draught, m | 3.20 |
| No of shafts | 2 |
| Machinery | 2 MTU 16V4000 M70 diesels |
| Power, h. p. | 6310 |
| Max speed, kts | 18 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | |
| Armament | none |
| Electronic equipment | Terma Scanter 6000 radar |
| Complement |
Graphics
Chundamani
Project history
Large patrol ships.
Modernizations
None.
Naval service
No significant events.
