NAVYPEDIA


Ratjabala 1967

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
601 Kelap Lintah 602 Kalamisani 603 Sarpawisesa 604 Sarpamina 605 Pulanggeni 606 Kalanada 607 Hardadedali 608 Sarotama 609 Ratjabala 610 Tritusta 611 Nagapasa 612 Guawidjadja	5 Yd, Leningrad or 602 Yd, Vladivostok, USSR: 601-612	1959-1962 // 1962: 601-606 1959-1964 // 9.1964: 607-610 1959-1965 // 1965: 611, 612	606 Hardadali (early 1976, wrecked)	None	1974: 604 1976: 607, 610 1979: 602, 608, 611 1981: 601, 603, 605, 609, 612

Technical data

Displacement standard, t	70
Displacement full, t	81
Length, m	25.5
Breadth, m	6.20
Draught, m	1.40
No of shafts	4
Machinery	4 M50F-4 diesels
Power, h. p.	4800
Max speed, kts	38
Fuel, t	diesel oil
Endurance, nm(kts)	885(11.8)
Armament	2 x 1 P-15 SSM (2 P-15), 1 x 2 - 25/80 2M-3M
Electronic equipment	Rangout radar
Complement	17

Standard scale images

Graphics

Project history

Former Soviet Project 183R FACs (missile).

Modernizations

None.

Naval service

Hardadedali sank early 1976 after hitting an underwater obstacle.
