Vijaya 2001

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
विक्रम [Vikram]	33		Mazagon Dock, Bombay		29.9.1981	26.12.1983	stricken 1.2012
विजय [Vijaya]	34		Mazagon Dock, Bombay			12.4.1985	stricken 1.2012
वीरा [Veera]	35		Mazagon Dock, Bombay		30.6.1984	3.5.1986	stricken 5.2013
वरुणा [Varuna]	36		Mazagon Dock, Bombay		1.2.1984	27.2.1988	to Sri Lanka 8.2017 (සමුද්‍රරක්ෂ [Samudraraksha])
वज्रा [Vajra]	37		Mazagon Dock, Bombay		31.1.1987	22.12.1988	stricken 2.2018
विवेक [Vivek]	38		Mazagon Dock, Bombay		5.11.1987	19.8.1989	collision 23.3.2010
विग्रह [Vigraha]	39		Mazagon Dock, Bombay		1.12.1988	12.4.1990	to Sri Lanka 8.2009-1/2011 (සයුරළ [Sayurala]), stricken 5.2019
वरद [Varad]	40		Goa SYd		2.9.1989	19.7.1990	stricken 4.2017
वराह [Varaha]	41		Goa SYd			11.3.1992	to Sri Lanka 2.2007 (සාගර [Sagara])

Technical data

Displacement standard, t	1064
Displacement full, t	1224
Length, m	74.1
Breadth, m	11.4
Draught, m	3.50
No of shafts	2
Machinery	2 SEMT-Pielstick 16PA6 V280 diesels
Power, h. p.	12800
Max speed, kts	22
Fuel, t	diesel oil 180
Endurance, nm(kts)	4000(16)
Armament	1 x 1 - 40/60 Mk 3, 1 helicopter (Chetak)
Electronic equipment	Decca 1230, Decca 1226 radars
Complement	95

Standard scale images

Graphics

Project history

Patrol ships. Unsatisfactory design with bad seakeeping  abilities, ships can not operate helicopter in heavy weather due to rolling. Equipped with salvage pumps and firefighting monitors. Carry also 2 RIB inspection craft and a GRP launch.

Modernizations

2000s, all: - 1 x 1 - 40/60; + 1 x 1 - 30/80 Medak CRN-91

Naval service

Vivek collided 23.3.2010 with merchant vessel and sank.
