Azumanche 2004

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P651 Tecunuman, 1996- GC651 Tecunuman P652 Kaibil Balam, 1996- GC652 Kaibik Balam P653 Azumanche, 1996- GC653 Azumanche P654 Tzacol, 1996- GC654 Tzacol P655 Bitol, 1996- GC655 Bitol P656 Gucumaz, 1996- BH656 Gucumaz	Halter Marine, New Orleans, USA: P651-656	1971: P651 1972: P652, 653 1976: P654, 655 1981: P656	none	none	in service (2019): GC651-655, BH656

Technical data

Displacement standard, t	34
Displacement full, t	45
Length, m	19.7
Breadth, m	5.20
Draught, m	0.90
No of shafts	2
Machinery	2 General Motors 12V71 diesels
Power, h. p.	960
Max speed, kts	25
Fuel, t	diesel oil
Endurance, nm(kts)	400(15)
Armament	1 x 1 - 12.7/90, 3 x 1 - 7.6/90
Electronic equipment	radar
Complement	10

Graphics

Project history

US Cutlass type. Aluminium hull.

Modernizations

1991, all: - 1 x 1 - 12.7/90, 1 x 1 - 7.6/90; + 2 x 1 - 20/90 GAM-B01

1995, Tzacol, Gucumaz; 1997, Tecunuman, Kaibil Balan, Azumanche, Bitol: diesels were replaced by 2 General Motors 8V92TA (1300hp, 25kts)

Naval service

Gucumaz used as survey boat.
