Agios Efstafios 2004

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Φουρνοιγο [Fournoigo]	ΛΣ-060 [LS-060]		Israeli SY, Haifa, Israel			20.12.2003	in service (2019)
Ρο [Rho]	ΛΣ-070 [LS-070]		Israeli SY, Haifa, Israel			2/2004	in service (2019)
Άγιος Ευστράτιος [Agios Efstratios]	ΛΣ-080 [LS-080]		Hellenic SY, Skaramanga			4/2004	in service (2019)

Technical data

Displacement standard, t	400
Displacement full, t	450
Length, m	58.0
Breadth, m	7.80
Draught, m	2.40
No of shafts	4
Machinery	4 MTU 16V396 TB94 diesels
Power, h. p.	15000
Max speed, kts	33
Fuel, t	diesel oil
Endurance, nm(kts)	1600(18)
Armament	1 x 1 - 30/82 OTO-Breda 563, 2 x 1 - 12.7/90
Electronic equipment	2x radars
Complement	30

Standard scale images

Graphics

Project history

Israeli Sa'ar IV class, purchased to assist with coastal security operations during the 2004 Olympic Games.

Modernizations

None.

Naval service

No significant events.
