Zingst 1978 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Greifswald	301/316	224	Peenewerft, Wolgast			28.11.1970	stricken 4.1990, to Guinea-Bissau (Mawia)
Bergen	302	225	Peenewerft, Wolgast			29.5.1969	fishery protection vessel Warnemünde 5.1981, to Tunisia (راس إفريقيا [Ras Ifrikia])
Anklam	303	226	Peenewerft, Wolgast			30.5.1969	stricken 12.1976
Ückermünde, 1990- GS01	304, 1970s- G-11/G-441	227	Peenewerft, Wolgast			1.7.1969	Board Guard 1970s, stricken 10.1990, to Malta (P30)
Demmin, 1990- GS02	351/331, 1970s- G-12/G-442	228	Peenewerft, Wolgast			16.8.1969	Board Guard 1970s, stricken 10.1990, to Tunisia (راس البلاد [Ras el Blad])
Malchin, 1990- GS03	352/332, 1970s- G-13/G-441	229	Peenewerft, Wolgast			18.10.1969	Board Guard 1970s, stricken 10.1990, to Tunisia (راس أجدير [Ras Ajdir])
Altentreptow, 1990- GS04	353/333, 1970s- G-14/414	230	Peenewerft, Wolgast			5.9.1969	Board Guard 1970s, stricken 10.1990, to Tunisia (راس إدراك [Ras Edrak])
Pasewalk, 1990- GS05	354/314, 1970s- G-45/G-426	231	Peenewerft, Wolgast			18.10.1969	Board Guard 1970s, stricken 10.1990, to Malta (P31)
Templin, 1990- GS06	335, 1970s- G-16/G-442	232	Peenewerft, Wolgast			20.12.1969	Board Guard 1970s, stricken 10.1990, to Tunisia (راس منورة [Ras Manoura])
Neustrelitz	336/316, 1970s- G-41/G-412	233	Peenewerft, Wolgast			20.12.1969	Board Guard 1970s, deleted 2.1990
Vitte	G-21/G-421	234	Peenewerft, Wolgast			18.2.1970	Board Guard, deleted 2.1990
Zingst	G-22/G-444	235	Peenewerft, Wolgast			8.5.1970	Board Guard, stricken 3.1989
Prerow	G-23/G-413	236	Peenewerft, Wolgast			15.5.1970	Board Guard, stricken 3.1989
Graal-Müritz	G-24/G-424	237	Peenewerft, Wolgast			25.5.1970	Board Guard, stricken 10.1989
Kühlungsborn, 1990- GS07	G-25/G-445, 1992- BG32	238	Peenewerft, Wolgast			3.6.1970	Board Guard, reunification 10.1990, stricken 1996, to Cape Verde (Vigilante)
Ahrenshoop, 1990- GS08	G-26/G-415, 1992- BG33	239	Peenewerft, Wolgast			8.8.1970	Board Guard, reunification 10.1990, to Tunisia 8.1997 (راس انغيلا [Ras Enghela])
Kirchdorf	G-42/G-425	240	Peenewerft, Wolgast			19.9.1970	Board Guard, deleted 8.1990
Boltenhagen, 1990- GS09	G-43/G-443, 1992- BG31	241	Peenewerft, Wolgast			19.9.1970	Board Guard, reunification 10.1990, to Malta 7.1997 (P29)
Klütz	G-46/G-416	242	Peenewerft, Wolgast			3.10.1970	Board Guard, deleted 2.1990
Rerik	G-45/G-426	243	Peenewerft, Wolgast			12.11.1970	Board Guard, deleted 2.1990
Bansin	G-46/G-446	244	Peenewerft, Wolgast			24.12.1970	Board Guard, deleted 2.1990

Technical data

Displacement standard, t	339
Displacement full, t	377
Length, m	52.0
Breadth, m	7.10
Draught, m	2.40
No of shafts	2
Machinery	2 40DM diesels
Power, h. p.	5000
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)	2000(15)
Armament	2 x 2 - 25/80 2M-3M, SDGR/L USV, GKT-1 mechanical, HFG-13, HFG-24 magnetic, AT-2 acoustic minesweeping gear, 30 mines
Electronic equipment	TSR-333 radar, KLA-58M sonar
Complement	24

Standard scale images

Graphics

Project history

Replacements tor 'Habicht' and 'Krake' classes. These smaller, more numerous boats reflected changes in Volksmarine mine warfare operational concepts. First boat, after prolonged trials, entered service as experimental ship V-31. First production boat laid down October 1967 and twenty-one were built by Peenewerft, Wolgast.

Modernizations

late 1980s, all: + 1 x 4 Strela-3M SAM (4 Strela-3M)

Naval service

: In the mid-1970s all were transferred to the Frontier Guard (retaining their sweeping gear), and renumbered in 'G' series, apart from Anklam, Bergen and Greifsioald which became training ships. Upon deletion Bergen became the fishery' protection vessel Warnemünde (with enlarged superstructure) and was retained in this role after reunification by the German Ministry of Agriculture and Fisheries.
