S134 1918 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Chastang (ex-S133)		1006	Schichau, Elbing, Germany	1916	1.9.1917	2.1918 // 7.1920	stricken 8.1933
Vesco (ex-S134)		1007	Schichau, Elbing, Germany	1917	25.8.1917	1.1918 // 6.1920	stricken 7.1935
Mazaré (ex-S135)		1008	Schichau, Elbing, Germany	1917	27.10.1917	3.1918 // 7.1920	stricken 7.1935
Deligny (ex-S139)		1012	Schichau, Elbing, Germany	1917	24.11.1917	4.1918 // 7.1920	stricken 8.1933

Technical data

Displacement normal, t	919
Displacement full, t	1170
Length, m	82.5 wl 83.1 oa
Breadth, m	8.32
Draught, m	3.60 normal 3.90 deep load
No of shafts	2
Machinery	2 Schichau steam turbines, 3 Marine boilers
Power, h. p.	24000
Max speed, kts	32
Fuel, t	oil 300
Endurance, nm(kts)	2450(17)
Armament	3 x 1 - 105/42 Tbts L/45 C/16, 2 x 2 - 500 TT, 2 x 1 - 500 TT (8), 24 mines
Complement	105

Standard scale images

Graphics

Project history

Ex-German destroyers of S131 class, received by reparations.

Modernizations

None.

Naval service

No significant events.

Many thanks to Wolfgang Stöhr for additional information on this page.
