Flamant 2008

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Flamant	P676		CMN, Cherbourg	3.1994	24.4.1995	18.12.1997	in service (2019)
Cormoran	P677		Leroux & Lotz, Lorient	25.5.1994	15.5.1995	29.10.1997	in service (2019)
Pluvier	P678		CMN, Cherbourg	1995	2.12.1996	18.12.1997	in service (2019)

Technical data

Displacement standard, t	314
Displacement full, t	390
Length, m	48.5 pp 54.0 oa
Breadth, m	9.80
Draught, m	2.60 hull 2.90 propellers
No of shafts	2
Machinery	2 Deutz-MWM TBD 620 V16 diesels + 2 Deutz-MWM TBD 234 V12 diesels
Power, h. p.	6000 + 1960 = 7960
Max speed, kts	23
Fuel, t	diesel oil 55
Endurance, nm(kts)	14000(7.5)
Armament	2 x 1 - 12.7/90
Electronic equipment	Decca 250, Decca 20V90 ARPA radars
Complement	20

Standard scale images

Graphics

Project history

PSP (Patrouilleurs de Service Public), ordered in 1992, but construction was delayed by the closure of the original contract yard. Based on the commercial Espadon 50 design, employing a deep-vee hull form capable of operating at speed in Sea State 4. They have a stern embarkation ramp for an Hurricane 7-metre water-jet rigid inflatable inspection boat capable of 30kts, and accommodation for up to 22 passengers. A 400m³/hr fire-fighting monitor is installed, and there are two 7m³ capacity spill recovery holding tanks. Main engines can be used in different combinations.

Modernizations

1998, Cormoran; late 2000s, Flamant, Pluvier: + 2 radars (additionally)

2016-2018, all: - all radars; + 2x DRBN-34 radars

Naval service

No significant events.
