27 de Febrero 1951

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
27 de Febrero (ex-PC613)	P101		Gibbs Gas Engine, Jacksonville, USA	7.1942	27.10.1942	6.1943 // 1947	discarded 1968
Capitán Wenceslao Arvelo (ex-PC1207), 1962- Patria	P102		Consolidated SB, New York, USA	6.1943	18.8.1943	11.1943 // 1947	discarded 1962
Cibas (ex-PC1597, ex-Engage), 1962- Constitución	P103		Dravo, Pittsburgh, USA	2.1942	11.7.1942	10.1942 // 1947	discarded 1968

Technical data

Displacement standard, t	414
Displacement full, t	463
Length, m	51.8 wl 52.9 oa
Breadth, m	7.06
Draught, m	3.30 full load
No of shafts	2
Machinery	2 diesels
Power, h. p.	P101, 102: 2880 P103: 1800
Max speed, kts	P101, 102: 19 P103: 17
Fuel, t	diesel oil 49
Endurance, nm(kts)	3000 (12)
Armament	1 x 1 - 76/50 Mk 21, 1 x 1 - 40/60 Mk 3, 1 x 1 - 20/70 Mk 10
Electronic equipment	SF or SO or SU radar
Complement	59 - 65

Standard scale images

Graphics

Project history

Former USN PC class submarine chasers.

Modernizations

None.

Naval service

No significant events.
