Mosvig 1970 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Asvig	M579	195	Orlogsværftets, København	4/1959	11.5.1960	9.1961	stricken 8.1974
Mosvig	M580	196	Orlogsværftets, København	4/1959	14.9.1960	10.1961	stricken 8.1974
Sandvig	M581	197	Orlogsværftets, København	5/1960	1.3.1961	2.1962	stricken 8.1974
Sælvig	M582	198	Orlogsværftets, København	9/1960	14.7.1961	4.1962	stricken 8.1974

Technical data

Displacement standard, t	180
Displacement full, t	200
Length, m	32.5 pp 35.4 oa
Breadth, m	7.20
Draught, m	1.70
No of shafts	2
Machinery	2 diesels
Power, h. p.	1100
Max speed, kts	14
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	1 x 1 - 20/70 Mk 10, mechanical, magnetic, acoustic minesweeping gear
Electronic equipment	NWS-3 radar
Complement	14

Standard scale images

Graphics

Project history

Danish design.

Modernizations

None.

Naval service

No significant events.
