Dubhe 2013

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
MHV801 Aldebaran MHV802 Carina MHV803 Aries MHV804 Andromeda MHV805 Gemini MHV806 Dubhe MHV807 Jupiter MHV808 Lyra MHV809 Antares MHV810 Luna MHV811 Apollo MHV812 Hercules MHV813 Baunen MHV814 Budstikken MHV815 Kureren MHV816 Patrioten MHV817 Partisan MHV818 Sabotøren, 1993- MHV851 Sabotørren	Soby Værft, Æro: MHV801-818	1992: MHV801, 802 1993: MHV803, 804 1994: MHV805-807 1995: MHV808, 809 1996: MHV810, 811 1997: MHV812, 813 1998: MHV814 1999: MHV815 2000: MHV816, 817 2001: MHV818	no	no	in service (2019): MHV801-817, 851

Technical data

Displacement standard, t	80
Displacement full, t	83
Length, m	20.3 pp 23.7 oa
Breadth, m	5.60
Draught, m	2.00
No of shafts	2
Machinery	2 Scania DSI14V8 diesels
Power, h. p.	900
Max speed, kts	13
Fuel, t	diesel oil
Endurance, nm(kts)	990(11)
Armament	2 x 1 - 7.6/92
Electronic equipment	Furuno 1505 radar
Complement	12

Graphics

Project history

Patrol boats for the Naval Home Guard. GRP hull.

Modernizations

2013, Sabotøren: was lengthened (97t full load, 27.2m oa)

Naval service

No significant events.
