NAVYPEDIA


OMm35 1939

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
OMm35 OMm36	Škoda, Komárno: OMm35, 36	10/1938: OMm35	OMm35 (4/1939 German FM1); OMm36 (incomplete to Germany 1939 as FM2)	none	none

Technical data

Displacement standard, t
Displacement full, t	60
Length, m	31.0
Breadth, m	4.16
Draught, m	0.92 max
No of shafts	2
Machinery	2 Sulzer diesels
Power, h. p.	900
Max speed, kts
Fuel, t	diesel oil
Endurance, nm(kts)
Armour, mm	turret: 48, CT: 6
Armament	1 x 2 - 7.9/90, 2 x 1 - 7.9/90, 18 - 22 mines
Complement	6

Standard scale images

Graphics

Project history

Armoured minelaying boat, first combat boat of Czechoslovakia, specially designed for military service.

Ship protection

Only fwd MG turret was enough protected.

Modernizations

None.

Naval service

No significant events.
