20 de Julio 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
20 de Julio	PZE46		Cotecmar, Cartagena	3.2009	28.7.2010	3.2.2012	in service (2019)
7 de Agosto	PZE47		Cotecmar, Cartagena	2011	4.9.2013	17.3.2014	in service (2019)
Victoria (ex-Santander)	PZE48		Cotecmar, Cartagena	29.12.2014	1.12.2016	8.7.2017	in service (2019)

Technical data

Displacement standard, t	1500
Displacement full, t	1730
Length, m	74.4 pp 80.6 oa
Breadth, m	13.0
Draught, m	3.80
No of shafts	2
Machinery	2 Wärtsilä 6L26 diesels
Power, h. p.	11100
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)	8600(12)
Armament	PZE46: 1 x 1 - 40/70 Breda-Bofors 315, 1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90, 1 helicopter (BO-105 or Bell 412) PZE47: 1 x 2 - 40/70 OTO-Breda Compact Twin 40, 1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90, 1 helicopter (BO-105 or Bell 412) PZE48: 1 x 1 - 76/62 OTO-Melara Compact, 1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90, 1 helicopter (BO-105 or Bell 412)
Electronic equipment	Scanter 4100, nav. radars, SP-100 CCS
Complement	40

Standard scale images

Graphics

Project history

Fassmer OPV 80 design. Carry Midnight Express interceptor on the stern ramp.

Modernizations

None.

Naval service

No significant events.
