CHANGZHENG 11 ballistic missile nuclear-powered submarines (projects 094, 094A, 2007-)
2007
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate | Modification |
|---|---|---|---|---|---|---|---|---|
| 长征11号 [Changzheng 11] | 411 | Bohai, Huludao | 28.7.2004 | 3/2007 | in service (2019) | Type 094 | ||
| 长征13号 [Changzheng 13] | 413 | Bohai, Huludao | 2006 | 1.10.2009 | in service (2019) | Type 094 | ||
| 长征12号 [Changzheng 12] | 412 | Bohai, Huludao | 12/2009 | 2011 | in service (2019) | Type 094A | ||
| 长征14号 [Changzheng 14] | 414 | Bohai, Huludao | 2011 | 2012 | in service (2019) | Type 094A | ||
| 长征20号 [Changzheng 20] | 420 | Bohai, Huludao | 2014 | 2019 | building (2019) | Type 094A |
Technical data
| Displacement standard, t |
|
|---|---|
| Displacement normal, t | 9000 / 11000 |
| Length, m | 137.0 |
| Breadth, m | 12.5 |
| Draught, m | 7.50 |
| No of shafts | 1 |
| Machinery | 2 sets geared steam turbines, 2 nuclear reactors |
| Power, h. p. | 20000 |
| Max speed, kts | / 26 |
| Fuel, t | nuclear |
| Endurance, nm(kts) | practically unlimited |
| Armament | 12 Ji Lang-2 SLBM (12 JL-2), 6 - 533 TT (bow, 12) |
| Electronic equipment | type 359 radar, H/SQG-4 sonar suite (TSM2233 Eledone, TSM-2255, SQB-2 sonars), H/SQC-207 sonar, Type 921-A (SRW209) ECM suite, CCS |
| Complement | 140 |
| Diving depth operational, m | 300 |
Standard scale images
Changzheng 11 2010
Graphics
2007
Project history
Type 094 became absolutely new Chinese SSBN, far more quieter than type 092, armed with new JL-2 SLBMs, equipped with new powerplant and electronics. Noise level is reported as quieter than type 093 SSN but louder than Russian project 667BDR SSBN. Fourth submarine becomes to type 094A, she has streamlined hull, superstructure and sail and is quieter than predecessors.
Modernizations
None.
Naval service
No significant events.
