CHENGDU frigates (project 01, 1957-1958)

Chengdu 1965

Chengdu 1980

Name No Builder Laid down Launched Comp Fate
昆明 <Kunming> 205, 1980- 505 Hudong, Shanghai 15/4/1955 28/4/1956 30/5/1957 stricken 4/1992
成都 <Chengdu> 206, 1980- 506 Hudong, Shanghai 8/1955 26/9/1956 1957 stricken 1994
贵阳 <Guiyang>, 1980- 凭祥 <Pinghsiang> 207, 1980- 507 Hudong, Shanghai 9/1955 1957 1958 stricken 1995
衡阳 <Henyang>, 1980- 西昌 <Sichang> 208, 1980- 508 Hudong, Shanghai 3/1956 1957 6/1958 stricken 1993



Displacement standard, t

1050

Displacement normal, t

1337

Length, m

90.9

Breadth, m

10.2

Draught, m

2.90

No of shafts

2

Machinery

TV-9 geared steam turbines, 2 KVG-57/28 boilers

Power, h. p.

20000

Max speed, kts

29

Fuel, t

oil

Endurance, nm(kts) 1000(14.5)

Armament

3 x 1 - 100/56 B-34USMA, 2 x 2 - 37/70 V-11M, 1 x 2 - 533 TT, 2 x 24 MBU-200 ASWRL, 4 DCT, 2 DCR

Sensors Giuys-1M4, Lin', Don, Yakor' radars, Pegas-2M sonar, Bizan'-4 ECM suite

Complement

168

Ship project history: These ships were assembled from Soviet components in Chinese shipyards and were of the Soviet Project 50.

Modernizations: 1971-1973, all: - 1 x 2 - 533 TT; + 1 x 2 Hai Ying-2 SSM (2 HY-2)

1978-1979, all: + 2 x 2 - 14.5/93

Naval service: No significant events.

Chengdu 1971

Ivan Gogin, 2015
