NANCHANG destroyers (2019-)
Ships
| Name | No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|
| 南昌 [Nanchang] | 101 | Jiangnan, Changxing | 12/2014 | 28.6.2017 | 2019 | trials (2019) |
| 102 | Jiangnan, Changxing | 2015 | 28.4.2018 | 2020 | building (2019) | |
| 181 | Dalian SB | 2015 | 3.7.2018 | 2020 | building (2019) | |
| 182 | Dalian SB | 2015 | 3.7.2018 | 2020 | building (2019) | |
| v | Jiangnan, Changxing | 2016 | 2019 | 2021 | building (2019) | |
| vi | Dalian SB | 2016 | 2019 | 2021 | building (2019) | |
| vii | Jiangnan, Changxing | 2017 | 2020 | 2022 | building (2019) | |
| viii | Dalian SB | 2017 | 2020 | 2022 | building (2019) |
Technical data
| Displacement standard, t | 11000 |
|---|---|
| Displacement full, t | 13500 |
| Length, m | 183.0 |
| Breadth, m | 22.0 |
| Draught, m | 8.00 |
| No of shafts | 2 |
| Machinery | COGAG: 4 QC-280ICR gas turbines |
| Power, h. p. | 156000 |
| Max speed, kts | 33 |
| Fuel, t | gas turbine oil |
| Endurance, nm(kts) | 5000(18) |
| Armament | (1 x 64 + 1 x 48) CJ-10 CruM / YJ-18 SSM / YJ-100 SSM / YJ-62 SSM / HQ-9 SAM / HQ-16 SAM (112 CJ-10 / YJ-18 / YJ-100 / YJ-62 / HQ-9 / HQ-16), 2 x 10 HQ-10 SAM (20 HQ-10), 1 x 1 - 130/70 H/PJ-45A, 1 x 11 - 30/77 H/PJ-11, 2 x 3 - 324 TT, 2 helicopters (Z-20F) |
| Electronic equipment | type 346B, type 517B, type 366, type 364, type 344A, type 349, 2x type 756 radars, 2x OFC-3 e/o directors, SJD-9, ALPR sonars, type 984/985, HZ-100 ECM suites, 4x type 726-4 decoy launchers, ZKJ-5 CCS |
| Complement |
Standard scale images
Nanchang 2019
Project history
Type 055 are main AA ships for Chinese carrier groups. They have two VLS grids, carrying many types of cruise, anti-ship, anti-aircraft ant anti-submarine missiles. Designed under USN 'Air-Sea battle' conception. Future replacement of the 130mm gun by rail-gun is planned.
Modernizations
None.
Naval service
No significant events.
