Pabna 2010

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P111 পাবনা [Pabna] P112 নোয়াখালী [Noakhali] P113 পটুয়াখালী [Patuakhali] P114 রাঙামাটি [Rangamati] P115 বগুড়া [Bogra]	DEW Narayengonj, Dhaka: P111-115	1972: P111, 112 1974: P113 1977: P114, 115	none	none	in service (2020): P111-115

Technical data

Displacement standard, t
Displacement full, t	70
Length, m	22.9
Breadth, m	6.10
Draught, m	1.10
No of shafts	2
Machinery	2 Cummins diesels
Power, h. p.
Max speed, kts	10
Fuel, t	diesel oil
Endurance, nm(kts)	700(8)
Armament	1 x 1 - 20/70 Mk 4
Electronic equipment	none
Complement	33

Graphics

Project history

First naval units built in Bangladesh. Design was based on river steamer construction.

Modernizations

2000s, all: + Furuno radar

Naval service

In 1995 Pabna and in 2003-2004 all other boats were transferred to Coast Guard.
