DURDHARSHA fast attack craft (missile) (1965-1975/1988-1992)





Dordanda 2003

Ships


Name No Yard No Builder Laid down Launched Comp Fate
দুর্ধর্ষ [Durdharsha] P8125   Hudong, Shanghai, China or Xijiang SY, Wuzhou, China     1965-1975 // 10.11.1988 in service (2020)
দুর্দান্ত [Durdanta] P8126   Hudong, Shanghai, China or Xijiang SY, Wuzhou, China     1965-1975 // 10.11.1988 in service (2020)
দুর্নিবার [Durnibar], 2002- সালাম [Salam] P8127, 2002- P712   Hudong, Shanghai, China or Xijiang SY, Wuzhou, China     1965-1975 // 10.11.1988 in service (2020)
দোর্দণ্ড [Dordanda] P8128   Hudong, Shanghai, China or Xijiang SY, Wuzhou, China     1965-1975 // 10.11.1988 in service (2020)
অনির্বান [Anirban] P8131   Hudong, Shanghai, China or Xijiang SY, Wuzhou, China     1965-1975 // 10.11.1988 in service (2020)


Technical data


Displacement standard, t

175
Displacement full, t

210
Length, m

38.8
Breadth, m

7.70
Draught, m

1.80
No of shafts

3
Machinery

3 42-160 diesels
Power, h. p.

12000
Max speed, kts

36
Fuel, t

diesel oil
Endurance, nm(kts)

800(30)
Armament

4 x 1 Hai Ying-2 SSM (4 HY-2), 2 x 2 - 25/80 type 81
Electronic equipment

type 352 radar
Complement

30


Standard scale images


<i>Durdharsha </i>1990
Durdharsha 1990


Graphics


<i>Dordanda </i>2003
Dordanda 2003
<i>Salam </i>2011
Salam 2011


Project history

Former Chinese type 021 FACs. Anirban was delivered in 1992 as a replacement for Durnibar badly damaged during the cyclone in April 1991 (but later repaired as patrol).

Modernizations

2002, Salam: diesels were replaced by 2 Paxman 12V185 (4800hp, 24kts, 3460(13)nm); - 4 x 1 Hay Ying-2 SSM, 2 x 2 - 25/80, type 352 radar; + 1 x 1 - 40/60 Mk 7, 1 x 2 - 30/75 GCM-A03, Furuno HR-2010, Anritsu radars

Naval service

Durnibar sunk in river Kamaphuli in April 1991 during cyclone, recovered and recommissioned as patrol craft Salam in 2002.
