Al Muharraq 2008

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
المنامة [Al Manama]	50		Lürssen, Vegesack, West Germany		1986	14.12.1987	in service (2020)
المحرق [Al Muharraq]	51		Lürssen, Vegesack, West Germany		1986	3.2.1988	in service (2020)

Technical data

Displacement standard, t	536
Displacement full, t	632
Length, m	59.9 pp 63.0 oa
Breadth, m	9.30
Draught, m	2.90
No of shafts	4
Machinery	4 MTU 20V538 TB93 diesels
Power, h. p.	19600
Max speed, kts	34
Fuel, t	diesel oil 120
Endurance, nm(kts)	4000(16)
Armament	2 x 2 MM40 Exocet SSM (4 MM40), 1 x 1 - 76/62 OTO-Melara Compact, 1 x 2 - 40/70 Breda-Bofors Compact Twin 40, 2 x 1 - 20/90 GAM-B01, 1 helicopter (AS.365F)
Electronic equipment	Decca 1226, 9LV331 (9LV200 radar with e/o system), Sea Giraffe 50HC radars, 2x Panda Mk 2 e/o systems, Cygnus, Cutlass B-1 ECM suites, 2x Dagaie decoy RL
Complement	43

Standard scale images

Graphics

Project history

Small craft, versatile missile corvettes armed also with helicopter. Big after superstructure under the helicopter deck contains helicopter hangar and a lift. Can serve as leadres for FAC squadrons providing over-horizon targeting for SSMs using the helicopter.

Modernizations

None.

Naval service

No significant events.
