Al Jarim 2003

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
30 الجرم [Al Jarim] 31 الجسرة [Al Jasrah]	Swiftships, Morgan City, USA: 30, 31	1982: 30, 31	none	none	in service (2020): 30, 31

Technical data

Displacement standard, t
Displacement full, t	33
Length, m	19.2
Breadth, m	5.56
Draught, m	1.98
No of shafts	2
Machinery	2 General Motors 12V71TI diesels
Power, h. p.	1200
Max speed, kts	30
Fuel, t	diesel oil
Endurance, nm(kts)	1200(18)
Armament	1 x 1 - 12.7/90
Electronic equipment	Decca 110 radar
Complement

Graphics

Project history

US 65ft Commercial Cruiser class. Aluminium construction.

Modernizations

1990s, both: - 1 x 1 - 12.7/90; + 1 x 1 - 20/90 GAM-B01

Naval service

No significant events.
