NO510 submarines (1956/1960-1961)
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| (ex-S-241) | 510, 1990- 331 | 444 Nosenko Yd, Nikolayev, USSR | 30.8.1955 | 23.1.1956 | 29.5.1956 // 5.1961 | stricken 1976 | |
| (ex-S-242) | 512, 1990- 523, 1993- 442 | 444 Nosenko Yd, Nikolayev, USSR | 28.9.1955 | 29.3.1956 | 30.6.1956 // 5.1961 | stricken 1991 | |
| Qemel (ex-S-360) | 514, 1990- 552, 1993- 422, 1995- 022 | 189 Ordzhonikidze Yd, Leningrad, USSR | 17.3.1955 | 29.4.1956 | 30.9.1956 // 5.1961 | stricken 1995 | |
| (ex-S-358) | 516, 1993- 423 | 189 Ordzhonikidze Yd, Leningrad, USSR | 3.1.1955 | 1.10.1955 | 24.5.1956 // 5.1961 | stricken 1995 |
Technical data
| Displacement standard, t |
|
|---|---|
| Displacement normal, t | 1045 / 1342 |
| Length, m | 76.0 |
| Breadth, m | 6.30 |
| Draught, m | 4.55 |
| No of shafts | 2 |
| Machinery | 2 37D diesels / 2 PG-101 electric motors |
| Power, h. p. | 4000 / 2700 |
| Max speed, kts | 18.3 / 13.1 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 8580(10) / 353(2) |
| Armament | 6 - 533 TT (4 bow, 2 stern, 12 or 22 mines) |
| Electronic equipment | Flag radar, Tamir-5L, Feniks sonars, Nakat ECM suite |
| Complement | 55 |
| Diving depth operational, m | 170 |
Standard scale images
No 510 1965
Graphics
Project history
Soviet Project 613 medium submarines were seized in 1961 upon the withdrawal of the Soviets from their base at Sazan Island.
Modernizations
None.
Naval service
No significant events.
